Indoor LCD Video Wall

Industrial A+ Grade Panel with 60,000 hours life span

High resolution, high contrast ratio, wide view angel

super-Narrow-splicing techniques

Built in Video splicing techniques

LED backlight, low power consumption, environment protection

Versatile signal ports, 1 VGA, 1 HDMI, 1 DVI, 1 CVBS

Computer management of individual screens

Metal frame, static-free, magnetic-free, free from strong electricity interference.

Fixed installation holes, quick installation

Certificate: CE, FCC, CCC

Panel Specification
Model NO	L DU46	L DU49	L DU55	L DU65
Display area(mm)	1018.96(H)*573.55(V)	1074.1(H)*604.3(V)	1209.80(H)*680.60(V)	1428.68(H)*803.72(V)
power consumption	≤260W	≤185w	≤200W	≤220W
Gross weight	25kg	30kg	34kg	44kg
Screen Ratio	16:9
panel Brand	LG/BOE/CS OT
Resolution	1920x1080pixels/1366x768pixels
Brightness	2500/700 nits(TYP.)
Contrast Ratio	3500:1
Viewing Angle	178′
Life Span	60000 hours
Response Time	≤2ms
Bezel	0.88mm/1.7mm/1.8mm/3.5 mm
color system	PAL/NTSC/SECAM
Installation	cabinet wall-mounted Floor stand Modular stand Front-maintenance
power input	AC100240V,50/60HZ
standby power consumption	<=0.5w
software character	Easy operation,different system compatibility like windowsx/NT/2000/xp/win7etc
signal ports	USB &VGA&DVI&HDMI &signal control port(full screen display,separate screendisplay,partial screen display)
video format	MPEG-1,MPEG-2,MPEG-4,H.264,H.265,Rv etc.,support up to 1080P
Audio format	MP3/WMA/AAc etc
photo	JPG/BMP/GlF/TIFF/PNG and etc
operating Temperature	0℃~50℃
operating Humidity	10″90%
storage Temperature	-20C65C
casing Material	Full metal casing, anti-static,anti-magnetic field,and resistant to strong electricalfield interference
color	Front/Back-Black
